CZL638 Parallel Beam Load Cell Sensor (Recommended Solution Component)

Product Introduction
To provide our clients with a complete smart scale solution, iBodyinfo selects and offers the high-performance CZL638 Parallel Beam Load Cell. This sensor has been rigorously tested to work seamlessly with our BIA measurement modules, providing accurate and stable weight measurement for your final product. We offer it as a standard recommended component to simplify your procurement process and ensure overall system performance.

Core Advantages

• High Precision & Stability: Features a C2/C3 accuracy class with low comprehensive error, ensuring reliable data over long-term use in various applications.

• IP65 Protection: Offers excellent protection against dust and water ingress, making it suitable for complex production and operational environments.

• Compatible Design: A recommended platform size of 400x400mm and standardized specifications make it widely applicable for various electronic counting and weighing scale designs.

• Multiple Capacities: Available in a range of capacities from 150kg to 300kg to flexibly meet diverse product design requirements.

Technical Highlights

• Accuracy Class: C2 / C3

• Sensitivity: 2.0±0.2 mv/v

• Excitation Voltage: 9～12 V(DC)

• Protection Class: IP65

• Wiring Code: Red(+) Black(-) for Excitation, Green(+) White(-) for Signal

Applicable Scenarios

• Electronic counting scales

• Electronic weighing scales

• As the core weight measurement component for body composition analyzers or smart scales

Partnership Commitment
At iBodyinfo, our commitment is to provide a complete turnkey BIA solution. We not only develop the core BIA measurement modules but also rigorously select high-quality compatible components like the CZL638 load cell sensor to ensure your final product is robust, reliable, and performs exceptionally, accelerating your time-to-market.
